Description
Specifications
| Number of Ports | 8 x 10Base-T 100Base-TX 1000Base-T (1 Gbps) RJ-45 2 x (10 Gbps) SFP+ |
|---|---|
| Switching Protocol | Ethernet |
| Switching Layers | Layer 2 Layer 3 |
| Network/Transport Protocol | DHCP IGMP STP RSTP LLDP |
| Networking Compliant Standards | IEEE 802.1X |
| Networking Features | Jumbo Frames Support 6 Ports PoE+ 2 Ports PoE++ |
| Device Location | External |
| Mounting Capability | Desktop |
| Certifications | CE, FCC, IC |
| LAN | 8 (RJ-45) |
| SFP+ | 2 |
| Power Supply | Internal AC 100-240 V, max 2 A |
| Power over Ethernet | External DC 44-57 V |
| Power Consumption Operational | 120 W |
| Depth (mm) | 200 mm |
| Height (mm) | 44 mm |
| Width (mm) | 248 mm |
| Nominal Weight | 2.1 kg |
| External Color | White |
| Maximum Operating Ambient Temperature | 45 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 365 mm |
| Pack Width (mm) | 84 mm |
| Pack Height (mm) | 260 mm |
| Pack Weight Brutto (kg) | 3 kg |
| Pack Weight Netto (kg) | 2.96 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 523 mm |
| Box Width (mm) | 381 mm |
| Box Height (mm) | 300 mm |
| Box Weight Brutto (kg) | 17.756 kg |
| Retail Packaging Net Weight Carton | 0 kg |
| Retail Packaging Net Weight Plastic | 0 kg |
| Packs in Box | 6 |
| Package Type | Retail |
| EAN Code | 810084692691 |
