Description
Specifications
| Number of Ports | 16 x 10Base-T 100Base-TX 1000Base-T (Ethernet Fast Ethernet Gigabit Ethernet) 2 x Fibre Channel (1 Gbps) |
|---|---|
| Status Indicator | Link Speed PoE |
| Networking Compliant Standards | IEEE 802.1X IEEE 802.3af IEEE 802.3at |
| Networking Features | Jumbo Frames Support MDI MDI-X switch Switching Radius Authenticated Device Access 8 Ports PoE |
| Mounting Capability | Rackmount |
| Standard Rack Height | 1U |
| Certifications | CE, FCC, IC |
| LAN | 16 (RJ-45) |
| SFP | 2 |
| Power Supply | Internal AC 100-240 V, 50 60 Hz |
| Maximum Output Power | 60 W |
| Depth (mm) | 442.4 mm |
| Height (mm) | 43.7 mm |
| Width (mm) | 200 mm |
| Nominal Weight | 2.8 kg |
| External Color | Gray |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 521 mm |
| Pack Width (mm) | 123 mm |
| Pack Height (mm) | 313 mm |
| Pack Weight Brutto (kg) | 3.6305 kg |
| Pack Weight Netto (kg) | 2.6 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 547 mm |
| Box Width (mm) | 262 mm |
| Box Height (mm) | 348 mm |
| Box Weight Brutto (kg) | 8.271 kg |
| Retail Packaging Net Weight Carton | 2.9 kg |
| Retail Packaging Net Weight Plastic | 2.9 kg |
| Packs in Box | 2 |
| Package Type | Box |
| EAN Code | 817882028547 |
