Description
Specifications
| UPS Technology | Line Interactive |
|---|---|
| Output Power Capacity | 1000 W |
| Maximum Electrical Power Rating | 1500 VA |
| Nominal Output Voltage | 220 240 V |
| Certifications | CE, IEC 62040-1 |
| Voltage Phase | Single |
| Status Notification Method | Alarm LED |
| Circuit Protection | Over Current Short Circuit Protection Over Load |
| Output Waveform | Sinewave |
| Maximum Output Voltage | 240 V |
| Minimum Output Voltage | 220 V |
| Maximum Output Frequency | 60 Hz |
| Minimum Output Frequency | 50 Hz |
| IEC-320 C13 | 8 |
| Maximum Input Voltage | 280 V |
| Minimum Input Voltage | 170 V |
| Maximum Input Frequency | 60 Hz |
| Minimum Input Frequency | 50 Hz |
| Input Power Connectors Quantity | 1 |
| Input Power Connectors Type | IEC-320 C14 |
| Battery Location | internal |
| Battery Recharge Time | 8 hr |
| LAN Interface Quantity | 2 |
| Management Port Quantity | 1 |
| Management Port Connector Type | RJ-45 |
| Ethernet 10Base-T/100Base-TX Port Quanti | 2 |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 95 % |
| Minimum Operating Ambient Temperature | 0 °C |
| Minimum Operating Humidity | 0 % |
| Maximum Non-Operating Ambient Temperatur | 50 °C |
| Minimum Non-Operating Ambient Temperatur | -20 °C |
| Max. Altitude Operating | 3000 m |
| External Color | Gray |
| Mounting Capability | Rackmount |
| Standard Rack Height | 2 U |
| Included Accessories | Quick Start Guide |
| Depth (mm) | 442.4 mm |
| Height (mm) | 87.4 mm |
| Width (mm) | 300 mm |
| Nominal Weight | 13.7 kg |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 12 month(s) |
| Warranty Validation Criteria | Serial Number |
| Pack Length (mm) | 442 mm |
| Pack Width (mm) | 300 mm |
| Pack Height (mm) | 87 mm |
| Pack Weight Brutto (kg) | 14 kg |
| Pack Weight Netto (kg) | 13.7 kg |
| Pieces in pack | 1 |
| Box Weight Brutto (kg) | 1 kg |
| Packs in Box | 1 |
| Package Type | Retail |
| EAN Code | 0 |
