Description
Specifications
| Number of Ports | 28 |
|---|---|
| Number of Ports | 22 x (2.5 Gbps) RJ-45 2 x (10 Gbps) RJ-45 4 x (10 Gbps) SFP+ |
| Switching Layers | Layer 2 Layer 3 |
| MAC Address Table Size | 32K |
| Network/Transport Protocol | IPv4 DHCP QoS IGMP STP RSTP LLDP |
| Networking Compliant Standards | IEEE 802.1X |
| Networking Features | DHCP Server Built-in Jumbo Frames Support Egress Rate Limit Flow Control Storm Control Multicast & Broadcast Rate Limiting Port Isolation Port Mirroring Loop Protection 24 Ports PoE++ |
| Device Location | Plug-in Module |
| Mounting Capability | Rackmount |
| Standard Rack Height | 1U |
| Certifications | CE, FCC, IC |
| LAN | 24 (RJ-45) |
| SFP+ | 4 |
| Power Supply | Internal AC 100-240 V, 50 60 Hz |
| Depth (mm) | 400 mm |
| Height (mm) | 44 mm |
| Width (mm) | 442 mm |
| Nominal Weight | 6.2 kg |
| External Color | Gray |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 541 mm |
| Pack Width (mm) | 123 mm |
| Pack Height (mm) | 522 mm |
| Pack Weight Brutto (kg) | 7.86 kg |
| Pack Weight Netto (kg) | 6 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 555 mm |
| Box Width (mm) | 265 mm |
| Box Height (mm) | 555 mm |
| Box Weight Brutto (kg) | 16.8 kg |
| Retail Packaging Net Weight Carton | 0 kg |
| Retail Packaging Net Weight Plastic | 0 kg |
| Packs in Box | 2 |
| Package Type | Retail |
| EAN Code | 810084696606 |
