Description
Specifications
| Number of Ports | 48 x 10Base-T 100Base-TX 1000Base-T (Ethernet Fast Ethernet Gigabit Ethernet) 4 x (10 Gbps) |
|---|---|
| Switching Layers | Layer 3 |
| Status LED Indicators | Link, Speed, PoE |
| Networking Compliant Standards | IEEE 802.1D(Spanning Tree Protocol) IEEE 802.1X IEEE 802.3af IEEE 802.3at IEEE 802.3bt |
| Networking Features | Jumbo Frames Support Auto-sensing per port Support for RADIUS authentication 8 Ports PoE 40 Ports PoE+ |
| Device Location | Plug-in Module |
| Mounting Capability | Rackmount |
| Certifications | CE, FCC, IC |
| LAN | 48 (RJ-45) |
| SFP+ | 4 |
| Power Supply | Internal AC 100-240 V, 50 60 Hz |
| Maximum Output Power | 660 W |
| Power Consumption Operational | 60 W |
| Depth (mm) | 399.6 mm |
| Height (mm) | 43.7 mm |
| Width (mm) | 442.4 mm |
| Nominal Weight | 6.25 kg |
| External Color | Metal |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 521 mm |
| Pack Width (mm) | 123 mm |
| Pack Height (mm) | 512 mm |
| Pack Weight Brutto (kg) | 7.484 kg |
| Pack Weight Netto (kg) | 6.12 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 537 mm |
| Box Width (mm) | 262 mm |
| Box Height (mm) | 547 mm |
| Box Weight Brutto (kg) | 15.95 kg |
| Retail Packaging Net Weight Carton | 6.34 kg |
| Retail Packaging Net Weight Plastic | 6.34 kg |
| Packs in Box | 2 |
| Package Type | Box |
| EAN Code | 817882027656 |
