Description
Specifications
| Network Device Type | Firewall Gateway |
|---|---|
| Data Link Protocol Supports (New) | LAN |
| CPU | ARM Cortex-A57 |
| CPU Core Quantity | 4 |
| Internal Clock Rate | 1.7 GHz |
| Installed RAM | 2 GB |
| WAN | 1 x 1GbE RJ-45 1 x 10GbE SFP+ |
| LAN | 1 x 1GbE RJ-45 1 x 10GbE SFP+ |
| Standard Rack Height | 1 U |
| Device Location | Plug-in Module |
| Status LED Indicators | Activity Status |
| Certifications | CE, FCC, IC |
| Built-in Devices | LCD Touchscreen Display Reset Button |
| Included Accessories | Quick Start Guide |
| LAN | 1 (RJ-45) |
| SFP+ | 1 |
| WAN | 1 (RJ-45), 1 (SFP+) |
| Power Device Location | Internal |
| Maximum Input Frequency | 60 Hz |
| Minimum Input Frequency | 50 Hz |
| Maximum Input Voltage | 240 V |
| Minimum Input Voltage | 200 V |
| Maximum Power Consumption | 30 W |
| Width (mm) | 285.6 mm |
| Height (mm) | 43.7 mm |
| Depth (mm) | 442 mm |
| Nominal Weight | 3.43 kg |
| External Color | Gray |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 95 % |
| Minimum Operating Ambient Temperature | -10 °C |
| Minimum Operating Humidity | 5 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 521 mm |
| Pack Width (mm) | 123 mm |
| Pack Height (mm) | 415 mm |
| Pack Weight Brutto (kg) | 4.75 kg |
| Pack Weight Netto (kg) | 3 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 537 mm |
| Box Width (mm) | 262 mm |
| Box Height (mm) | 455 mm |
| Box Weight Brutto (kg) | 10.412 kg |
| Retail Packaging Net Weight Carton | 3.42 kg |
| Retail Packaging Net Weight Plastic | 3.42 kg |
| Packs in Box | 2 |
| Package Type | Box |
| EAN Code | 810010073525 |
