Description
TP-LINK Router Archer NX500 5G
Specifications
| Model | Archer NX500 |
|---|---|
| Description | 5G AX3000 Wireless Dual-Band Gigabit Router Boost Your 5G Speed - Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences. AX3000 Dual-Band Wi-Fi 6 Speed - 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz). Plug & Play - Enjoy 5G network right after inserting a SIM card. EasyMesh-Compatible - Co-work with EasyMesh products, to provide a more flexible and cost-effective Mesh network with a single Wi-Fi name for seamless whole-home coverage. Gigabit WAN/LAN Port - The gigabit WAN/LAN port enables NX500 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. Superior 5G A Revolutionary Experience Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences. At the same time, NX500 is backward compatible with 4G mode. Share 5G Speed with Reliable Wi-Fi Thanks to cutting-edge 5G tech, NX500 boosts up to 4.67 Gbps download speeds fulfills your devices needs. Armed with WiFi 6 technology, NX500 is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh WiFi to enjoy the future network that loads faster and connects more. Plug and Play, Enjoy 5G Network Everywhere Simple, just one SIM card Traditional broadband or cable installation is expensive and time-consuming for your vacation home, farm, or suburban warehouse. Long contract periods also create headaches for short-rentals, pop-up venues, and temporary shops to access the internet. Archer NX500 ensures a comfortable and no-block network installation. Plug in your SIM card and enjoy high-speed internet! Flexibly Create Whole Home Mesh WiFi If you have any dead zones at home, just add another Easymesh-Compatible router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection. Available WAN Connection Backup The gigabit WAN/LAN port enables NX500 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 5G/LTE connection works as a backup to provide a sustained and reliable internet connection for you. Easy Setup and Use Set up the Archer NX500 in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings, including Parental Controls and Access Control, from any Android or iOS device. Tether also provides Automatic Firmware Updates to always give your network the latest performance and security. |
| Type | xDSL |
| Type | v |
| Type | GSM 3G/4G |
| Data transmission | HSPA+ |
| Data transmission | 5G |
| Data transmission | LTE |
| Data transmission | HSDPA |
| Data transmission | HSPA |
| Data transmission | UMTS |
| UMTS network | 850 MHz |
| UMTS network | 900 MHz |
| UMTS network | 2100 MHz |
| LTE network | 3500 MHz |
| LTE network | 2600 MHz |
| LTE network | 700 MHz |
| LTE network | 800 MHz |
| LTE network | 850 MHz |
| LTE network | 900 MHz |
| LTE network | 1800 MHz |
| LTE network | 2100 MHz |
| LTE network | 2300 MHz |
| LTE network | 2500 MHz |
| LTE network | 3700 MHz |
| Aero2 support | No |
| Standards | 802.11ax |
| Standards | IPv4 |
| Standards | 802.11n |
| Standards | 802.11a |
| Standards | 802.11g |
| Standards | IPv6 |
| Standards | 802.11ac |
| Standards | 802.11b |
| Operating frequency | 5 GHz |
| Operating frequency | 2,4 GHz |
| Number of antennas | 11 |
| Number of antennas | Two connectors |
| Antenna | Detachable external |
| Antenna | Built-in |
| Security | DoS Protection IPv4 SPI Firewall IPv6 SPI Firewall IP and MAC Address Binding Access Control |
| Management, monitoring, configuration | Quality of Service - Traffic Prioritization by Device or Application Management - TP-Link Cloud, Local Management, Remote Management DHCP - Server, DHCP Client List, Address Reservation Port Forwarding - ALG, Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS - TP-Link, DynDns, NO-IP VPN - PPTP VPN, IPSec VPN, OpenVPN Access Control - Parental Controls, Local Management Control Firewall Security - DoS Attack Protection, SPI Firewall, Address/Domain Filtering, IP and MAC Address Binding |
| Card reader | None |
| I/O ports | 1 x 10/100/1000 Mbit/s LAN / WAN (Combo) |
| I/O ports | 1 x SIM card slot |
| I/O ports | 2 x 10/100/1000 Mbit/s |
| SIM card | Nano |
| Power supply | External Power Supply Input: 100-240V~50/60 Hz 0.6A Output: 12V DC / 2A |
| Certificates | CE RoHS |
| Supported operating systems | Windows 11 |
| Supported operating systems | Linux |
| Supported operating systems | Unix |
| Supported operating systems | Windows 8.1 |
| Supported operating systems | Novell NetWare |
| Supported operating systems | Mac OS |
| Supported operating systems | Windows 7 |
| Supported operating systems | Windows 8 |
| Supported operating systems | Windows 10 |
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or another browser with JavaScript enabled Active Nano SIM card |
| Environment requirements | Operating temperature: 0°C-40°C (32°F -104°F) Storage temperature: -40°C-70°C (-40°F -158°F) Humidity: 10%-90%, non-condensing Storage humidity: 5%-90%, non-condensing |
| Accessories included | Archer NX500 Power supply with 1.5m cable RJ45 Ethernet cable Quick installation guide |
| Color | White |
| Dimensions | 99 x 99 x 190 mm |
| Other features | Transmission speed: 574 Mbps in the 2.4 GHz band, 2402 Mbps in the 5 GHz band |
