Specifications
| Device Location | Plug-in Module |
|---|---|
| Form Factor | M.2 22x80mm |
| Storage Capacity | 500 GB |
| Supports Data Channel | PCIe NVMe 4.0 x4 |
| Certifications | BSMI, CAN ICES-3(B) NMB-3(B), CB-Scheme, CE, FCC, KCC, Morocco, RCM, TÜV, UL, VCCI, UKCA |
| Memory Technology | 3D NAND |
| Flash Memory Cell Technology | Quad-Level Cell |
| Included Accessories | Quick Start Guide |
| External Color | Blue |
| Maximum Random Read Rate | 660000 IOPS |
| Maximum Random Write Rate | 1100000 IOPS |
| Maximum Sequential Read Rate | 6600 MB s |
| Maximum Sequential Write Rate | 5600 MB s |
| Total Bytes Written (TBW) | 300 TB |
| Mean Time Between Failures | 17500000 hr |
| Shock Tolerance Operating | 1500G @ 0.5ms |
| Vibration Tolerance Operating | 5G @ 10-2000Hz |
| Vibration Tolerance Storage | 4.9G @ 7-800Hz |
| Maximum Power Consumption | 3.8 W |
| Maximum Operating Ambient Temperature | 85 °C |
| Minimum Operating Ambient Temperature | 0 °C |
| Maximum Non-Operating Ambient Temperatur | 85 °C |
| Minimum Non-Operating Ambient Temperatur | -40 °C |
| Width (mm) | 22 mm |
| Height (mm) | 2.38 mm |
| Depth (mm) | 80 mm |
| Nominal Weight | 5.7 g |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 60 month(s) |
| Warranty Validation Criteria | Serial Number |
| Pack Length (mm) | 80 mm |
| Pack Width (mm) | 21 mm |
| Pack Height (mm) | 2 mm |
| Pack Weight Brutto (kg) | 0.049 kg |
| Pack Weight Netto (kg) | 0.01 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 102 mm |
| Box Width (mm) | 21 mm |
| Box Height (mm) | 126 mm |
| Box Weight Brutto (kg) | 0.521 kg |
| Packs in Box | 10 |
| Package Type | Box |
| EAN Code | 718037906287 |
