Description
Smart wall switch for blinds SONOFF MINI-RBS-E Matter
SONOFF Orb-RBS is a smart wall switch designed for convenient control of blinds, curtains and shutters. The device is part of the Fusion series and works with Matter over Wi-Fi technology, which ensures broad compatibility with popular smart home platforms. This allows you to integrate it with Apple Home, Google Home, Alexa, Samsung SmartThings or Home Assistant, all using one common standard. Only the Matter hub is required for it to work - once added, you can manage blinds throughout your home from a single app.
Precise control
Orb-RBS allows you not only to open and close the blinds, but also to adjust them precisely within a selected range - for example, 30% for gentle brightening in the morning or 70% in bright sunlight. With the slider available on the mobile app, you can smoothly and precisely adjust the position of the blinds as you are comfortable.
Voice and local control
The switch works locally, even if the internet is temporarily down. If you're using a voice assistant at home-for example, Alexa, Siri or Google Assistant-you can use a single voice command to close the blinds at exactly 60% or completely open them without moving from your seat.
Automations and schedules
Orb-RBS allows you to create simple and advanced scenes and schedules. You can set the blinds to automatically raise at 7:00 in the morning and close at 8:00 in the evening - helping to maintain the natural rhythm of the day, as well as save energy. Combining with a door sensor or motion sensor also allows you to create privacy-enhancing scenes - the blinds can close themselves when you leave the house.
Easy and quick installation
Installation of the switch is simple and possible in both type 86 boxes and standard round boxes (⌀60 mm). You can mount it alone or in a multi-module frame - horizontally or vertically - depending on the interior layout. This way the device not only works practically, but also looks good in any room.
| Manufacturer | Sonoff |
|---|---|
| Product name | Orb-RBS |
| Series | Fusion |
| Model | MINI-RBS-E |
| Microcontroller (MCU) | ESP32 |
| Power supply | 100-240V~, 50/60Hz, max. 1A (motor) |
| Wireless connectivity | IEEE 802.11 b/g/n, 2.4 GHz (Wi-Fi) |
| Weight | 84,7 g |
| Dimensions | 86 × 86 × 34 mm |
| Color | White |
| Case material | PC plastic (polycarbonate) |
| Recommended wire diameter | From 18AWG to 14AWG (copper, solid or wire only) |
| Place of application | For indoor use |
| Working temperature | From -10°C to +40°C |
| Working humidity | 5-95% RH, non-condensing |
Producer: Shenzhen Sonoff Technologies Co., Ltd. (CN)
Address: Bulong Road, A, 518000, Shenzhen
Email: support@itead.cc
EU Responsible Person: SONOFF TECHNOLOGY Deutschland GmbH
Address: Breite Str. 22, 22, 40213, Düsseldorf
Email: eurep@itead.cc
