Description
Specifications
| System Type | MultiBoard |
|---|---|
| System Form Factor | All-in-One |
| Built-in Devices | Card Reader Light Sensor NFC Camera 8 M-pixel |
| Flash Types Supported | SD |
| Included Accessories | Remote Control Quick Start Guide Warranty card 6 Writing Pens Multi Pen Preinstalled Software |
| Multi-touch | Yes |
| Display Form Factor | Built-in |
| Display Type | LCD |
| Display Technology | IPS TFT |
| Viewable Display Diagonal Length | 86" |
| Maximum Resolution | 3840x2160@60Hz |
| Image Aspect Ratio | 16:9 |
| Pitch Type | Dot Pitch |
| Pitch Width | 0.4935 mm |
| Image Brightness | 400 cd m^2 |
| Image Contrast | 5 000 : 1 |
| Maximum Response Time | 8 ms |
| Image Max. V-View Angle | 178 ° |
| Image Max. H-View Angle | 178 ° |
| Display Features | Anti-Glare Direct LED UHD Tempered Glass 40 Point Touch-Screen 9H Hardness |
| Life Time | 50000 hr |
| HDMI In | 2 |
| DisplayPort | 1 |
| USB | 2 (USB Type C) |
| VGA | 1 (15-pin D-sub) |
| Audio Line-In | 1 (3.5-mm minijack) |
| LAN | 2 (RJ-45) |
| USB 2.0 | 1 (USB 2.0 (type A)) |
| USB 3.0 | 4 (USB 3.0 (Type A)) |
| Touch | 3 |
| Microphone-In | 1 (3.5-mm minijack) |
| S/PDIF | 1 |
| Serial | 1 (RS-232) |
| HDMI Out | 1 |
| Audio Line-Out | 1 (3.5-mm minijack) |
| CPU | ARM Cortex-A73 ARM Cortex-A53 |
| CPU Core Quantity | 8 |
| Chipset | A311D2 |
| Memory Type | DDR4 SDRAM |
| Memory Capacity | 8 GB |
| EMMC | 64 GB |
| Audio Controller Form Factor | integrated |
| Audio Output Mode | 2.1 Channel Surround |
| Number of Speakers | 2 |
| Output Power per Channel | 16 W |
| Subwoofer Output Power | 16 W |
| LAN | Yes |
| Wi-Fi | Dual Wi-Fi |
| Wi-Fi Main Chipset | Mediatek MT7663BU+Realtek RTL8822C |
| Wi-Fi Band Frequency | 2.4 5 GHz |
| Wi-Fi Standard | 802.11 a, b, g, n, ac |
| Bluetooth | Yes |
| Power Device Type | Power Supply |
| Power Device Location | Internal |
| Maximum Output Power | 460 W |
| Power Consumption Stand By/Sleep | 0.5 W |
| External Color | Black |
| Mounting Capability | Wallmount |
| Flat Display Mounting Interface | 800x600mm |
| Included Accessories | Remote Control Quick Start Guide Warranty card 6 Writing Pens Multi Pen Preinstalled Software |
| Cable Included | HDMI Cable Power Cable (EU UK) USB Touch Cable |
| Compatibility | PC PMB528K002, PC PMB528K003 |
| Height (mm) | 1207.7 mm |
| Depth (mm) | 105.6 mm |
| Width (mm) | 1961.8 mm |
| Nominal Weight | 66.7 kg |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 36 month(s) |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | up to 24 months extended (optional) |
| Pack Length (mm) | 2160 mm |
| Pack Width (mm) | 225 mm |
| Pack Height (mm) | 1310 mm |
| Pack Weight Brutto (kg) | 79.4 kg |
| Pack Weight Netto (kg) | 66.7 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 2160 mm |
| Box Width (mm) | 225 mm |
| Box Height (mm) | 1310 mm |
| Box Weight Brutto (kg) | 79.4 kg |
| Retail Packaging Net Weight Carton | 1 kg |
| Retail Packaging Net Weight Plastic | 0.1 kg |
| Packs in Box | 1 |
| Package Type | Retail |
| EAN Code | 8595248158467 |
