Description
Specifications
| Power Device Type | Power Supply |
|---|---|
| Power Device Location | Internal |
| Input Voltage | AC 100 240 V |
| Input Frequency | 47 63 Hz |
| Output Voltage | DC 3.3 5 ±12 V |
| Maximum Output Power | 750 W |
| Circuit Protection | Over Voltage Short Circuit Protection Over Power |
| Modular Power Supply | Semi |
| Power Adapter and Power Supply Features | Active PFC Automatic Fan Control RGB LED |
| 80 Plus Certification | 80 Plus Gold |
| Efficiency | 91.19% |
| +3.3V | 20 A (100 W) |
| +5V | 20 A (100 W) |
| +12V | 62 A (750 W) |
| -12V | 0.3 A (3.6 W) |
| +5VSB | 2.5 A (12.5 W) |
| 20+4-pin Main Connector | 1 |
| 4/8-pin +12V Power Connector | 1 |
| 4-pin Peripheral Power Connector | 3 |
| 4-pin Floppy Drive Connector | 1 |
| S-ATA Connector | 8 |
| 6/8-pin PCI Express Connector | 4 |
| Fans Installed Quantity | 1 |
| Fan Diameter | 140 mm |
| External Color | Black |
| Cable Included | Power Cord Modular Cables |
| Included Accessories | Cable Ties User Guide Screws |
| Depth (mm) | 160 mm |
| Height (mm) | 86 mm |
| Width (mm) | 150 mm |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 36 month(s) |
| Warranty Validation Criteria | Serial Number |
| Pack Weight Brutto (kg) | 2.25 kg |
| Pack Weight Netto (kg) | 1.56 kg |
| Pieces in pack | 1 |
| Box Weight Brutto (kg) | 2.25 kg |
| Retail Packaging Net Weight Carton | 0.4 kg |
| Retail Packaging Net Weight Plastic | 0.15 kg |
| Packs in Box | 1 |
| Package Type | Retail |
| EAN Code | 4260455644969 |
