Description
Gigabyte Motherboard X870 AORUS INFINITY AM5 4DDR5 ATX
Specifications
| Description | X870 AORUS INFINITY X3D Turbo Mode 2.0 : Incredible X3D performance unleashed by AI DDR5 OC up to 11400MT/s Daul DriverBIOS : Wi-Fi Driver Pre-install, Power-On & EZ to Launch the Network. AMD Socket AM5 : Supports AMD Ryzen(TM) 9000 / 8000 / 7000 Series Processors Digital twin 18+2+2 phases VRM solution Exclusive onboard Overclocking Kit for Extreme Overclocking PCIe EZ-Latch Up : Easy, Safe, and Scratch-Free GPU Removal Design WIFI EZ-Mag : Magnetic design for quick and easy Wi-Fi antenna installation M.2 EZ-Flex : high-efficiency heat dissipation & flexible patented baseplate for M.2 SSD M.2 EZ-Latch Click & Plus : Quick Release & Screwless Design on M.2 slots and heatsinks Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW Ultra-Fast Storage : 3*M.2 slots, including 2* PCIe 5.0 x4 PCB Thermal Plate : 14% thermal improvement and reinforced motherboard stability. Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard Extention Fast Networking : 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna Extended Connectivity : HDMI, USB4 Type-C with DP-Alt, Front QC-USB 65W PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card |
|---|---|
| Model | X870 AORUS INFINITY |
| CPU socket | Socket AM5 |
| Processor family | AMD Ryzen |
| Integrated CPU | No |
| Chipset manufacturer | AMD |
| Chipset type | AMD X870 |
| Memory type | DDR5 |
| Number of DDR5 slots | 2 |
| Memory bus frequency | 11400 MHz |
| Memory bus frequency | 6600 MHz |
| Memory bus frequency | 6800 MHz |
| Memory bus frequency | 7600 MHz |
| Memory bus frequency | 7800 MHz |
| Memory bus frequency | 8200 MHz |
| Memory bus frequency | 5600 MHz |
| Memory bus frequency | 6000 MHz |
| Memory bus frequency | 6400 MHz |
| Memory bus frequency | 9600 MHz |
| Memory bus frequency | 4800 MHz |
| Memory bus frequency | 8000 MHz |
| Memory bus frequency | 5200 MHz |
| Memory bus frequency | 4400 MHz |
| Memory bus frequency | 7200 MHz |
| Memory bus frequency | 6200 MHz |
| Memory bus frequency | 7000 MHz |
| Memory bus frequency | 9200 MHz |
| Memory bus frequency | 8400 MHz |
| Memory bus frequency | 8600 MHz |
| Memory bus frequency | 8800 MHz |
| Memory bus frequency | 6666 MHz |
| Max memory size | 128 |
| Expansion slots | 2 x PCIe x 16 |
| Max. number of SATA devices | 4 |
| RAID | Yes |
| Graphics | Integrated Graphics Processor with AMD Radeon(TM) Graphics support+ASMedia USB4 Controller: 1 x USB4 USB Type-C port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz Integrated Graphics Processor with AMD Radeon(TM) Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz |
| Sound card | Realtek(R) ALC1220 CODEC DTS :X(R) Ultra High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Network interface | 1 x 10/100/1000/2500/5000 Mbit/s |
| Network interface | Bluetooth |
| Network interface | Wi-Fi 802.11a/b/g/n/ac/ax/be |
| Network interface | LAN: Realtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) Wireless Communication module Qualcomm Wi-Fi 7 QCNCM865 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.4 Support for 11be 320MHz wireless standard |
| USB ports at back panel | 8 |
| USB ports on motherboard | 7 |
| Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports | 6 |
| Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports | 3 |
| FireWire (IEEE 1394) | No |
| COM connector / port | No |
| LPT connector / port | No |
| External connectors | 1 x S/PDIF |
| External connectors | 1 x OC Ignition button |
| External connectors | 3 x USB 3.2 Gen 2 Type-A |
| External connectors | 1 x PS/2 Keyboard |
| External connectors | 1 x PS/2 Mouse |
| External connectors | 1 x Q-Flash Plus button |
| External connectors | 1 x Line Out |
| External connectors | 1 x MIC |
| External connectors | 2 x SMA |
| External connectors | 4 x USB 3.2 Gen 1 Type-A |
| External connectors | 1 x HDMI |
| External connectors | 1 x RJ-45 |
| External connectors | 1 x USB4 Type-C |
| Onboard connectors | 1 x CPU Clock up button |
| Onboard connectors | 1 x Front panel audio header |
| Onboard connectors | 1 x TPM header |
| Onboard connectors | 1 x RGB LED strip header |
| Onboard connectors | 3 x Addressable LED |
| Onboard connectors | 1 x 4pin CPU fan |
| Onboard connectors | 4 x SATA III 6Gb/s |
| Onboard connectors | 2 x USB 3.2 Gen 1 Type-A |
| Onboard connectors | 1 x 4pin CPU/Water Pump Fan Connector |
| Onboard connectors | 4 x USB 2.0/1.1 |
| Onboard connectors | 1 x System panel header |
| Onboard connectors | 1 x Clear CMOS jumper |
| Onboard connectors | 2 x 8pin 12V |
| Onboard connectors | 4 x 4pin Chassis fan |
| Onboard connectors | 1 x 24pin ATX zasilanie |
| Onboard connectors | 1 x Cold Reset button |
| Onboard connectors | 1 x BIOS switch |
| Onboard connectors | 1 x OC Trigger switch |
| Onboard connectors | 1 x CPU Clock down button |
| Onboard connectors | 1 x 8-pin PCIe |
| Onboard connectors | 2 x 4pin case fan liquid cooling |
| Onboard connectors | 1 x HDMI |
| Onboard connectors | 3 x M.2 |
| Onboard connectors | 1 x USB 3.2 Gen 2x2 Type-C |
| Special functions | Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup |
| BIOS | 2 x 512 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS(TM) PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form factor | E-ATX |
| Dimensions | 30.5 x 27.5 cm |
| Supported operating systems | Windows 11 |
| Software | Norton Internet Security (OEM version) |
