Description
General Information
- SKU: 1451040
- Manufacturer Product Page: ASROCK B860M-H2
- Manufacturer Code: B860M-H2
- Catalog: Mainboards for Intel CPUs
- EAN: 4711581490437
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBI |
| Unit Box Height | 0.06 |
| Unit Box Length | 0.28 |
| Unit Box Width | 0.24 |
| M.2 | 3 |
| PCI-Express 4.0 16x | 1 |
| PCI-Express 4.0 1x | 2 |
| Audio port | 3 |
| HDMI | 2 |
| RJ45 | 1 |
| USB 2.0 | 2 |
| USB 3.2 type B | 3 |
| USB-C | 1 |
| SATA | Yes |
| USB 2.0 | Yes |
| USB 3.2 | Yes |
| USB-C | Yes |
| Chipset | Intel B860 Express |
| Socket | LGA1851 |
| Form Factor | Micro-ATX |
| Memory type | DDR5 |
| Memory slots | 2 |
| Integrated video | Depending on CPU |
| Integrated LAN | Gigabit |
| Integrated audio | Realtek ALC897 |
| RAID | SATA 0, 1, 5, 10 |
| Included Accessories | - 1 x I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket |
| Units per Pallet | 0 |
| Units per Shipping Box | 20 |
| Unit Calculated Volume | 0.004423 |
| Product Net Weight | 0.5 |
| Unit Calculated Weight | 0.798 |
Description
B860M-H2
Built to deliver reliable performance with versatile features, perfect for daily tasks.
- Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851)
- 5+1+1+1+1 Power Phase
- 2 x DDR5 DIMMs
- Supports Dual Channel, up to 8333+ (OC)
- 1 PCIe 4.0 x16, 2 PCIe 4.0 x1, 1 M.2 Key E for WiFi
- Graphics Output Options: 2 HDMI
- Realtek ALC897 7.1 CH HD Audio Codec
- 4 SATA3
- 1 Blazing M.2 (PCIe Gen5x4)
- 1 Hyper M.2 (PCIe Gen4x4)
- 1 USB 3.2 Gen2x2 Type-C (Rear)
- 1 USB 3.2 Gen1 Type-C (Front)
- 5 USB 3.2 Gen1 (3 Rear, 2 Front)
- 6 USB 2.0 (2 Rear, 4 Front)
- Realtek Gigabit LAN
- Supports BIOS Flashback
- 1 x I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket
