Description
General Information
- SKU: 1443241
- Manufacturer Product Page: DAHUA DHI-LM22-J200
- Manufacturer Code: DHI-LM22-J200
- Catalog: Monitors
- EAN: 6939554966293
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | LC3 |
| Unit Box Height | 0.37 |
| Unit Box Length | 0.56 |
| Unit Box Width | 0.11 |
| Backlight type | Edge LED |
| Colour depth | 8 |
| Colour gamut standard | NTSC |
| Contrast ratio (typical) | 1000:1 |
| Display brightness (typical) | 250 |
| Display diagonal | 21.5 |
| Display diagonal (metric) | 56 |
| Display resolution | 1920 x 1080 |
| Display technology | LED |
| Haze rate | 25 |
| HD type | Full HD |
| LED backlight | Yes |
| Maximum refresh rate | 100 |
| Native aspect ratio | 16:9 |
| NTSC coverage (typical) | 50 |
| Panel type | IPS |
| Pixel pitch | 0.24795 x 0.24795 |
| Response time | 5 |
| Screen shape | Flat |
| Surface hardness | 3H |
| Touchscreen | No |
| Viewable size, horizontal | 476.064 |
| Viewable size, vertical | 267.786 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Flicker-free technology | Yes |
| Operating hours (hours/days) | 24/7 |
| Built-in camera | No |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 |
| Detachable stand | Yes |
| Feet colour | Black |
| Frameless design | Yes |
| Front bezel colour | Black |
| Product colour | Black |
| Audio output | Yes |
| Built-in USB hub | No |
| HDMI | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Height adjustment | No |
| LED indicators | Yes |
| Panel mounting interface | 75 x 75 |
| Plug and Play | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -6 - 27 |
| VESA mounting | Yes |
| Wall mountable | Yes |
| AC adapter output voltage | 12 |
| Current rating | 2 |
| Energy consumption (SDR) per 1000 hours | 10 |
| Energy efficiency class (SDR) | C |
| Power consumption (max) | 13.6 |
| Power consumption (standby) | 0.5 |
| Power consumption (typical) | 10.4 |
| Power supply type | External |
| Operating relative humidity (H-H) | 10 - 85 |
| Operating temperature (T-T) | 0 - 40 |
| Storage relative humidity (H-H) | 5 - 90 |
| Storage temperature (T-T) | -20 - 60 |
| Bezel width (bottom) | 17.9 |
| Bezel width (side) | 2.4 |
| Bezel width (top) | 2.4 |
| Depth (without stand) | 37.5 |
| Height (without stand) | 294.1 |
| Weight (without stand) | 2500 |
| Width (without stand) | 489.9 |
| Package depth | 107 |
| Package height | 375 |
| Package type | Box |
| Package weight | 3400 |
| Package width | 556 |
| Cables included | HDMI |
| Manual | Yes |
| Power adapter included | Yes |
| Quick start guide | Yes |
| Stand included | Yes |
| Compliance certificates | CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD) |
| Mean time between failures (MTBF) | 50000 |
| Energy efficiency class | C |
| EPREL Registration Number | 2291298 |
| EPREL Version Number | 1 |
| Units per Pallet | 0 |
| Unit Calculated Volume | 0.02279 |
| Product Net Weight | 2.5 |
| Unit Calculated Weight | 3.4 |
Description
The Dahua J200 series CCTV monitor operates 24/7, delivering low power consumption and an extended lifespan. With its impressive 5 ms response time and a 100 Hz refresh rate, this monitor ensures that your images and videos are displayed without ghosting or blurring. Additionally, it is highly compatible with Dahua backend security devices, making it an excellent choice for various desktop displays and security video monitoring walls.
- FHD panel, suitable for continuous 24/7 operation
- 50,000 hours long lifetime, ultra-low power consumption
- 3 sides narrow bezel design, elegant appearance
- 5 ms fast response time with no image blurring or ghosting
- 178°/178° extra-wide viewing angle for overall viewing performance
- Supports multiple signal inputs including HDMI and VGA
Dahua Technology LM22-J200. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black
CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)
