Mainboard ASUS Intel B760 Express LGA1700 Micro-ATX Memory DDR4 Memory slots 4 1xPCI-Express 4.0 16x 2xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 2xUSB 3.2 1xPS/2 1xRJ45 3xAudio port PRIMEB760M-AD4-CSM

General Information

• SKU: 1439800
• Manufacturer Product Page: ASUS PRIME B760M-A D4-CSM
• Manufacturer Code: PRIME B760M-A D4-CSM
• Catalog: Mainboards for Intel CPUs
• EAN: 4711081984061
• Warranty: 36 months
• Currency: EUR
• Packaging Quantity: 1

Specifications

Description

PRIME B760M-A D4-CSM
Intel® B760 (LGA 1700) mATX motherboard, PCIe 4.0, two M.2 slots, Realtek 2.5Gb Ethernet, DisplayPort, Dual HDMI®, SATA 6 Gbps, rear USB 3.2 Gen 2, front USB 3.2 Gen 1 Type-C®, Aura Sync

• Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
• Intel® LGA 1700 Socket: Ready for 14th, 13th and 12th Gen Intel® processors
• Ultrafast Connectivity: PCIe 4.0, two M.2 slots, Realtek 2.5Gb Ethernet, rear USB 3.2 Gen 2, front USB 3.2 Gen 1 Type-C®
• Comprehensive Cooling: VRM heatsink, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+
• ASUS OptiMem II: Careful routing of traces and vias, plus ground layer optimizations to preserve signal integrity for improved memory overclocking
• Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware
• ASUS Control Center Express: Real-time IT monitoring and management software for enhanced data protection
