Description
General Information
- SKU: 1433270
- Manufacturer Product Page: ASROCK B850 PRO RS
- Manufacturer Code: B850 PRO RS
- Catalog: Mainboards for AMD CPUs
- EAN: 4711581490161
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBA |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.355 |
| Unit Box Width | 0.28 |
| M.2 | 1 |
| PCI-Express 4.0 16x | 1 |
| PCI-Express 5.0 16x | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| Microphone | 1 |
| RJ45 | 1 |
| USB 2.0 | 6 |
| USB 3.2 | 5 |
| USB-C | 1 |
| SATA | Yes |
| SATA 3.0 | Yes |
| USB 2.0 | Yes |
| USB 3.2 | Yes |
| USB-C | Yes |
| Chipset | AMD B850 |
| Socket | SAM5 |
| Form Factor | ATX |
| Memory type | DDR5 |
| Frequency speed | 8000 |
| Memory slots | 4 |
| Integrated video | Depending on CPU |
| Integrated audio | Realtek ALC897 |
| Integrated LAN | 2.5 Gigabit |
| RAID | SATA 0, 1, 10 |
| TPM | Header |
| Units per Shipping Box | 5 |
| Unit Calculated Volume | 0.008784 |
| Product Net Weight | 1.3 |
| Unit Calculated Weight | 2.16 |
Description
Modern and futuristic, with the attractive specifications and perfect balance, the Race Sport (RS) Edition is the evolution of the most popular PRO series motherboard. Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors 14+2+1 Phase Power Design, 80A Dr.MOS for VCore+SOC+MISC 4 x DDR5 DIMMs Supports Dual Channel, up to 8000+ (OC) PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 M.2 Key E for WiFi Graphics Output Options: 1 HDMI, 1 USB Type-C (DP-alt) Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio 1 Blazing M.2 (PCIe Gen5x4) 2 Hyper M.2 (PCIe Gen4x4) 1 Ultra M.2 (PCIe Gen3x4) 4 SATA3 1 USB 3.2 Gen2x2 Type-C (Front) 1 USB 3.2 Gen2 Type-C (Rear) 1 USB 3.2 Gen1 Type-C (Rear) 8 USB 3.2 Gen1 (4 Rear, 4 Front) 10 USB 2.0 (6 Rear, 4 Front) Realtek 2.5G LAN Supports M.2 Bottom Heatsink, BIOS Flashback
