Description
General Information
- SKU: 1432881
- Manufacturer Product Page: UBIQUITI USW-FLEX-2.5G-8-POE
- Manufacturer Code: USW-FLEX-2.5G-8-POE
- Catalog: Switches
- EAN: 810084695968
- Warranty: 12 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | SWI |
| Unit Box Height | 0.051 |
| Unit Box Length | 0.246 |
| Unit Box Width | 0.12 |
| Switch layer | L2 |
| Switch type | Managed |
| 10G Ethernet (copper) ports quantity | 1 |
| 2.5G Ethernet (copper) ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Power connector | DC-in jack |
| SFP+ module slots quantity | 1 |
| 10G support | Yes |
| Broadcast storm control | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 |
| Flow control support | Yes |
| Port mirroring | Yes |
| Rate limiting | Yes |
| Forwarding rate | 44.64 |
| Jumbo frames support | Yes |
| Switching capacity | 60 |
| Throughput | 30 |
| Loop protection | Yes |
| Multicast support | Yes |
| DIN rail mounting | Yes |
| Form factor | Desktop/Wall-Mounting |
| Housing material | Polycarbonate (PC) |
| LED indicators | Activity/Link/PoE/Power/Status |
| Product colour | White |
| Reset button | Yes |
| Wall mountable | Yes |
| DC input voltage | 54 |
| Input current | 3.9 |
| Power consumption (max) | 17 |
| Power source | AC/DC/PoE |
| Power supply included | No |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 15.4 |
| Power over Ethernet (PoE) voltage | 57 |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 1 |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 196 |
| Operating relative humidity (H-H) | 10 - 90 |
| Operating temperature (T-T) | -20 - 45 |
| Depth | 99.4 |
| Height | 33.5 |
| Weight | 567 |
| Width | 212.9 |
| Compliance certificates | CE/Federal Communications Commission (FCC)/Industry Canada (IC) |
| Units per Shipping Box | 12 |
| Unit Calculated Volume | 0.002471 |
| Unit Calculated Weight | 0.825 |
Description
Flexible, 8-port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with PoE+++ or an AC power adapter*.
*AC power adapter sold separately.
- (8) 2.5 GbE PoE++ output ports
- (1) 10 GbE PoE+++ input port for power / SFP+ port combo (57W PoE availability with PoE+++ input / 37W PoE availability with PoE++ input / 12W PoE availability with PoE+ input)
- 196W PoE availability with optional AC power adapter
Ubiquiti UniFi Flex 2.5G PoE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Switching capacity: 60 Gbit/s. DC input voltage: 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable, Form factor: Desktop/Wall-Mounting
2.5G Ethernet (100/1000/2500)
CE/Federal Communications Commission (FCC)/Industry Canada (IC)
UBIQUITI Flex 2.5G PoE
