Description
General Information
- SKU: 1415526
- Manufacturer Product Page: ASUS PRIMEA520M-R
- Manufacturer Code: PRIMEA520M-R
- Catalog: Mainboards for AMD CPUs
- EAN: 4711387466414
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBA |
| CnCode | 84733020 |
| Unit Box Height | 0.29 |
| Unit Box Length | 0.57 |
| Unit Box Width | 0.028 |
| Compatible processor series | AMD Ryzen 3000 Series/AMD Ryzen 5000 Series |
| Processor manufacturer | AMD |
| Processor socket | Socket AM4 |
| Supported processor sockets | Socket AM4 |
| ECC ?ompatibility | ECC |
| Maximum internal memory | 64 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Supported memory clock speed (max) | 5100 |
| Supported memory types | DDR5-SDRAM |
| Unbuffered memory | Y |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 5 |
| RAID levels | 0/1/10 |
| RAID support | Y |
| Supported storage drive interfaces | M.2,SATA III |
| Supported storage drive types | HDD & SSD |
| Parallel processing technology support | Not supported |
| 12V power connector | Y |
| ATX Power connector (24-pin) | Y |
| CPU fan connector | Y |
| Front panel audio connector | Y |
| Number of chassis fan connectors | 1 |
| Number of COM connectors | 1 |
| Number of SATA III connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| TPM connector | Y |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Headphone outputs | 1 |
| Line-in | Y |
| Microphone in | Y |
| PS/2 ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Audio output channels | 7.1 |
| Component for | PC |
| Cooling type | Passive |
| Motherboard chipset | AMD A520 |
| Motherboard chipset family | AMD |
| Motherboard form factor | Micro ATX |
| Power source type | ATX |
| Product colour | Black |
| Windows operating systems supported | Windows 10/Windows 11 |
| Number of M.2 (M) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| BIOS memory size | 128 |
| BIOS type | UEFI AMI |
| Package depth | 263 |
| Package height | 51.5 |
| Package weight | 880 |
| Package width | 270 |
| Depth | 193 |
| Width | 236 |
| Cables included | SATA |
| Units per Shipping Box | 10 |
| Unit Calculated Volume | 0.004628 |
| Unit Calculated Weight | 0.876 |
Description
ASUS PRIME A520M-R. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Ryzen 3000 Series, AMD Ryzen 5000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: Gigabit Ethernet. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: AMD
AMD Ryzen 3000 Series/AMD Ryzen 5000 Series
