Description
General Information
- SKU: 1399509
- Manufacturer Product Page: DAHUA NVR5232-EI
- Manufacturer Code: NVR5232-EI
- Catalog: NVR
- EAN: 6923172586018
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | NVR |
| Unit Box Height | 0.36 |
| Unit Box Length | 0.43 |
| Unit Box Width | 0.14 |
| Desktop/pedestal | Yes |
| Rack 1U | Yes |
| SATA | Yes |
| 15pin D-sub | 1 |
| Alarm In | 4 |
| Alarm Out | 2 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| RJ45 | 1 |
| RS232 | 1 |
| RS-485 | 1 |
| USB 2.0 | 1 |
| USB 3.0 | 1 |
| Number of Channels | 32 |
| Number of drives/bays | 2 |
| CPU | Embedded Linux |
| Power supply requirements | 12 VDC, 4 A |
| Power consumption | 10 |
| Dimensions | 375.0 × 284.4 x 56.0mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.02167 |
| Product Net Weight | 1.57 |
| Unit Calculated Weight | 2.81 |
Description
•32 IP channel max, up to 32MP resolution • up to 384 Mbps incoming bandwidth •VGA/HDMI up to 3840 × 2160 output •2 SATA interface up to 16 TB each •No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB •1U 19” chassis, mouse included •Free IP monitoring software available •Smart capabilities support: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus • Support AcuPick with Max. 16-Channel
375.0 × 284.4 x 56.0mm
