Description
General Information
- SKU: 1396865
- Manufacturer Product Page: DAHUA DHI-NVR5216-16P-EI
- Manufacturer Code: DHI-NVR5216-16P-EI
- Catalog: NVR
- EAN: 6923172589828
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | NVR |
| Unit Box Height | 0.42 |
| Unit Box Length | 0.45 |
| Unit Box Width | 0.15 |
| Desktop/pedestal | Yes |
| Rack | Yes |
| 15pin D-sub | 1 |
| Alarm In | 4 |
| Alarm Out | 2 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| RJ45 | 1 |
| RS232 | 1 |
| RS-485 | 1 |
| USB 2.0 | 1 |
| USB 3.0 | 1 |
| Number of Channels | 16 |
| Number of drives/bays | 2 |
| CPU | Industrial-grade processor |
| PoE ports | 16 |
| Power supply requirements | 100–240 VAC, 47-63 Hz |
| Dimensions | 375.0 mm × 329.3 mm x 53.0mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.02835 |
| Product Net Weight | 2.66 |
| Unit Calculated Weight | 3.95 |
Description
16 IP channel max, up to 32MP resolution Max 384 Mbps incoming Bandwidth VGA/HDMI up to 4K output, 16-channel 4 MP@30 fps 2 SATA interface up to 16TB, Gigabit LAN PoE Port: 16 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE; 130W max total No front panel controls, 4/2 alarm I/O, 1/1 Audio I/O, RS232, RS485, 2 USB 1U 19” chassis, mouse included AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting. Other brands IP cameras supported. ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK Free IP monitoring software available
375.0 mm × 329.3 mm x 53.0mm
