Description
General Information
- SKU: 1386732
- Manufacturer Product Page: ASROCK B650PGLIGHTNING
- Manufacturer Code: B650PGLIGHTNING
- Catalog: Mainboards for AMD CPUs
- EAN: 4710483940910
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBA |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.36 |
| Unit Box Width | 0.3 |
| M.2 | 3 |
| PCI-Express 4.0 16x | 2 |
| PCI-Express 4.0 1x | 2 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| Microphone | 1 |
| RJ45 | 1 |
| USB 2.0 | 4 |
| USB 3.2 | 7 |
| USB-C | 2 |
| SATA | Yes |
| USB 2.0 | Yes |
| USB 3.2 | Yes |
| Chipset | AMD B650 |
| Socket | SAM5 |
| Form Factor | ATX |
| Memory type | DDR5 |
| Frequency speed | 6400 |
| Memory slots | 4 |
| Integrated video | Depending on CPU |
| Integrated audio | Realtek ALC897 |
| Integrated LAN | 2.5 Gigabit |
| RAID | SATA 0, 1, 10; NVMe 0, 1, 10 |
| TPM | Header |
| Included Accessories | - 1 x User Manual - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.00864 |
| Product Net Weight | 1.4 |
| Unit Calculated Weight | 1.71 |
Description
- Supports AMD Ryzen™ 7000 Series Processors - 14+2+1 Phase Power Design, SPS - 4 x DDR5 DIMMs, supports up to 6400+(OC) - 2 PCIe 4.0 x16, 2 PCIe 4.0 x1, 1 M.2 Key-E for WiFi - Graphics Output Options: 1 HDMI - CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio - 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen4x2), 4 SATA3 - 1 USB 3.2 Gen2x2 Type-C (Rear), 1 USB 3.2 Gen2 Type-C (Front), 9 USB 3.2 Gen1 (7 Rear, 2 Front), 8 USB 2.0 (4 Rear, 4 Front) - Realtek 2.5G LAN
SATA 0, 1, 10; NVMe 0, 1, 10
- 1 x User Manual - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets
