Description
General Information
- SKU: 1386729
- Manufacturer Product Page: ASROCK B650PRORS
- Manufacturer Code: B650PRORS
- Catalog: Mainboards for AMD CPUs
- EAN: 4710483940750
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBA |
| Unit Box Height | 0.097 |
| Unit Box Length | 0.385 |
| Unit Box Width | 0.325 |
| M.2 | 3 |
| PCI-Express 3.0 16x | 1 |
| PCI-Express 4.0 16x | 1 |
| Audio port | 3 |
| DisplayPort | 1 |
| HDMI | 1 |
| RJ45 | 1 |
| USB 2.0 | 6 |
| USB 3.2 | 3 |
| USB-C | 1 |
| SATA | Yes |
| USB 2.0 | Yes |
| USB 3.2 | Yes |
| Chipset | AMD B650 |
| Socket | SAM5 |
| Form Factor | ATX |
| Memory type | DDR5 |
| Frequency speed | 6200 |
| Memory slots | 4 |
| Integrated video | Depending on CPU |
| Integrated audio | Realtek ALC897 |
| Integrated LAN | 2.5 Gigabit |
| RAID | SATA 0, 1; NVMe 0, 1, 10 |
| TPM | Header |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.01214 |
| Product Net Weight | 2 |
| Unit Calculated Weight | 2.09 |
Description
- Supports AMD Ryzen™ 7000 Series Processors - 14+2+1 Phase Power Design, SPS - 4 x DDR5 DIMMs, supports up to 6200+(OC) 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 1 PCIe 4.0 x1, 1 M.2 Key-E for WiFi - Graphics Output Options: 1 HDMI, 1 DisplayPort - 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio - 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen3x2 & SATA3), 4 SATA3 -1 USB 3.2 Gen2x2 Type-C (Front), 2 USB 3.2 Gen2 Type A+C (Rear), 4 USB 3.2 Gen1 (2 Rear, 2 Front), 9 USB 2.0 (6 Rear, 3 Front) -Realtek 2.5G LAN
SATA 0, 1; NVMe 0, 1, 10
