Description
General Information
- SKU: 1365540
- Manufacturer Product Page: DAHUA DH-PFS3106-4ET-60-V2
- Manufacturer Code: DH-PFS3106-4ET-60-V2
- Catalog: Switches
- EAN: 6923172506603
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | SWI |
| Unit Box Height | 0.078 |
| Unit Box Length | 0.27 |
| Unit Box Width | 0.24 |
| 10/100/1000M | 4 |
| IEEE 802.3 | Yes |
| IEEE 802.3ab | Yes |
| IEEE 802.3u | Yes |
| IEEE 802.3x | Yes |
| IEEE 802.3z | Yes |
| Primary port count | 4 |
| PoE power budget | 60 |
| Switching capacity | 6.8 |
| Forwarding rate | 3.57 |
| Dimensions | 150 mm × 100 mm × 30 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.005054 |
| Product Net Weight | 0.45 |
| Unit Calculated Weight | 1.09 |
Description
Unmanaged PoE switch > Eight-Pin assignment PoE power supply > Intelligent PoE > Hi-PoE 60W (Orange Port) > PoE watchdog > 250 m long distance PoE transmission > Wide operating temperature: –30°C to +65°C 1 Ethernet Port 1 Optical Port Port 1–4: 4 × RJ-45 10/100 Mbps (PoE) Port 5: 1 × RJ-45 10/100/1000 Mbps (Uplink) Port 6: 1 × SFP 100/1000 Mbps (Uplink) Capacity 6.80 Gbps Packet Forwarding Rate 3.57 Mpps Packet Buffer Memory 1 Mbit MAC Table Size 8K Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3X; IEEE 802.3ab; IEEE 802.3z PoE Standard: IEEE802.3af; IEEE802.3at; Hi-PoE PoE Power 60W 250 m long distance PoE transmission
150 mm × 100 mm × 30 mm
