Description
General Information
- SKU: 1327583
- Manufacturer Product Page: ASROCK B450PRO4R2.0
- Manufacturer Code: B450PRO4R2.0
- Catalog: Mainboards for AMD CPUs
- EAN: 4710483932786
- Warranty: 36 months
- Currency: EUR
- Packaging Quantity: 1
Specifications
| Category Code | MBA |
| Unit Box Height | 0.27 |
| Unit Box Length | 0.335 |
| Unit Box Width | 0.06 |
| Audio chip | Realtek ALC892 / Realtek ALC897 |
| Audio output channels | 7.1 |
| Certification | FCC, CE ErP/EuP |
| Component for | PC |
| Motherboard chipset | AMD B450 |
| Motherboard chipset family | AMD |
| Motherboard form factor | ATX |
| PC health monitoring | Fan/Temperature/Voltage |
| Windows operating systems supported | Windows 10 x64 |
| Compatible processor series | AMD Athlon/AMD Ryzen 3000 Series/AMD Ryzen 5000 Series |
| Maximum number of SMP processors | 1 |
| Processor manufacturer | AMD |
| Processor socket | Socket AM4 |
| ECC сompatibility | ECC & Non-ECC |
| Maximum internal memory | 128 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Supported memory clock speeds | 2133/2400/2667/2933/3200 |
| Supported memory types | DDR4-SDRAM |
| Unbuffered memory | Yes |
| RAID levels | 0/1/10 |
| RAID support | Yes |
| Supported storage drive interfaces | M.2,SATA III |
| DirectX version | 12.0 |
| HDCP | Yes |
| Maximum resolution | 4096 x 2160 |
| Number of displays supported | 3 |
| Parallel processing technology support | CrossFireX/Quad-GPU CrossFireX |
| 12V power connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Front panel audio connector | Yes |
| Number of chassis fan connectors | 3 |
| Number of COM connectors | 1 |
| Number of SATA III connectors | 6 |
| RGB LED pin header | Yes |
| TPM connector | Yes |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| PS/2 ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| LAN controller | Realtek RTL8111H |
| Wake-on-LAN ready | Yes |
| Wi-Fi | No |
| Number of M.2 (M) slots | 2 |
| PCI Express x1 (Gen 2.x) slots | 4 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| ACPI version | 5.1 |
| BIOS memory size | 128 |
| BIOS type | UEFI AMI |
| System Management BIOS (SMBIOS) version | 2.3 |
| Harmonized System (HS) code | 84733020 |
| Depth | 224 |
| Width | 305 |
| Bundled software | ASRock A-Tuning ASRock Polychrome SYNC ASRock XFast LAN |
| Cables included | SATA |
| Drivers included | Yes |
| Units per Pallet | 0 |
| Units per Shipping Box | 10 |
| Unit Calculated Volume | 0.00632 |
| Unit Calculated Weight | 1.44 |
Description
Asrock B450 Pro4 R2.0. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Athlon, AMD Ryzen 3000 Series, AMD Ryzen 5000 Series. Supported memory types: DDR4-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, RAID levels: 0, 1, 10. Parallel processing technology support: CrossFireX, Quad-GPU CrossFireX, Maximum resolution: 4096 x 2160 pixels. Ethernet interface type: Gigabit Ethernet, LAN controller: Realtek RTL8111H
AMD Athlon/AMD Ryzen 3000 Series/AMD Ryzen 5000 Series
ASRock A-Tuning ASRock Polychrome SYNC ASRock XFast LAN
