Description
Specifications
| Series | NUC |
|---|---|
| Model | NUC 15 Pro Plus |
| System Type | Personal Computer |
| System Form Factor | Mini |
| CPU | Intel® Core™ Ultra 5 Processor 225H |
| CPU Core Quantity | 14 |
| Threads | 14 |
| CPU Socket Standard | Socket 2049 |
| CPU Installed Quantity | 1 |
| CPU Maximum Quantity Supports | 1 |
| CPU Cache Size | 18 MB |
| Chipset | System on Chip (SoC) |
| Quantity of Mainboards Supported | 1 |
| Performance-cores Quantity | 4 |
| Efficient-cores Quantity | 8 |
| Memory Type | DDR5 SDRAM |
| Memory Form Factor | SODIMM 262-pin |
| Memory Speed | 5600MHz(PC5-44800) 6400MHz(PC5-51200) |
| Maximum Installable System Memory Storag | 96 GB |
| Memory Slot Total Quantity | 2 |
| Integrated | Storage Controller: PCIe NVMe ( x M.2) |
| Plug-in-card | Wi-Fi Controller: Intel Wi-Fi 7 BE201 |
| Video Controller Form Factor | Integrated |
| Video Chipset | Intel Arc Graphics |
| Video Memory Type | Shared Video Memory |
| Networking Form Factor | Integrated |
| Wi-Fi | IEEE 802.11be Wi-Fi 7 |
| Bluetooth | Bluetooth 5.4 |
| Data Link Protocol Supports | Gigabit Ethernet Fast Ethernet Ethernet 2.5 Gbps |
| USB 3.2 Gen 2 x2 | 1 (USB 3.2 (type C)) |
| USB 3.2 Gen 2 | 3 (USB 3.2 (type A)) |
| Thunderbolt 4 | 2 (USB Type C) |
| USB 2.0 | 1 (USB 2.0 (type A)) |
| HDMI | 2 (HDMI (Type A)) |
| LAN | 1 (RJ-45) |
| Power Device Type | Power Adapter |
| Power Device Location | External |
| External Color | Silver |
| Mounting Capability | Desktop |
| In the Box | Documentation |
| Cable Included | Power Cable (EU Plug) |
| Height (mm) | 42 mm |
| Depth (mm) | 112 mm |
| Width (mm) | 144 mm |
| Nominal Weight | 0.6 kg |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 36 month(s) |
| Warranty Validation Criteria | Serial Number |
| Pack Length (mm) | 172 mm |
| Pack Width (mm) | 160 mm |
| Pack Height (mm) | 121 mm |
| Pack Weight Brutto (kg) | 1.67 kg |
| Pack Weight Netto (kg) | 1.52 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 478 mm |
| Box Width (mm) | 319 mm |
| Box Height (mm) | 183 mm |
| Box Weight Brutto (kg) | 9.31 kg |
| Packs in Box | 5 |
| Package Type | Box |
| EAN Code | 4711387950241 |
