Description
Specifications
| Series | NUC |
|---|---|
| Model | NUC 14 Pro |
| System Type | Personal Computer |
| System Form Factor | Mini |
| CPU | Intel® Core™ Ultra 7 Processor 155H |
| CPU Core Quantity | 16 |
| Threads | 22 |
| CPU Socket Standard | Socket 2049 |
| CPU Installed Quantity | 1 |
| CPU Maximum Quantity Supports | 1 |
| CPU Cache Size | 24 MB |
| Chipset | System on Chip (SoC) |
| Quantity of Mainboards Supported | 1 |
| Performance-cores Quantity | 6 |
| Efficient-cores Quantity | 8 |
| Memory Type | DDR5 SDRAM |
| Memory Form Factor | SODIMM 262-pin |
| Maximum Installable System Memory Storag | 96 GB |
| Integrated | Storage Controller: PCIe NVMe 4.0 x4 (2 x M.2) Storage Controller: SATA |
| Plug-in-card | Wi-Fi Controller: Intel Wi-Fi 6E AX211 |
| Video Controller Form Factor | Integrated |
| Video Chipset | Intel Arc Graphics |
| Video Memory Type | Shared Video Memory |
| Audio Controller Form Factor | integrated |
| Networking Form Factor | Integrated |
| Wi-Fi | IEEE 802.11ax Wi-Fi 6E |
| Bluetooth | Bluetooth 5.3 |
| Data Link Protocol Supports | Gigabit Ethernet Fast Ethernet Ethernet 2.5 Gbps |
| USB 3.2 Gen 2 x2 | 1 (USB 3.2 (type C)) |
| USB 3.2 Gen 2 | 3 (USB 3.2 (type A)) |
| Thunderbolt 4 | 2 (USB Type C) |
| USB 2.0 | 1 (USB 2.0 (type A)) |
| HDMI | 2 (HDMI (Type A)) |
| LAN | 1 (RJ-45) |
| Power Device Type | Power Adapter |
| Power Device Location | External |
| Maximum Output Power | 120 W |
| External Color | Black |
| Mounting Capability | Desktop |
| In the Box | Warranty Card Quick Start Guide |
| Cable Included | Power Cable (EU Plug) |
| Height (mm) | 54 mm |
| Depth (mm) | 112 mm |
| Width (mm) | 117 mm |
| Nominal Weight | 0.617 kg |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 36 month(s) |
| Warranty Validation Criteria | Serial Number |
| Pack Length (mm) | 192 mm |
| Pack Width (mm) | 160 mm |
| Pack Height (mm) | 121 mm |
| Pack Weight Brutto (kg) | 1.51 kg |
| Pack Weight Netto (kg) | 0.62 kg |
| Pieces in pack | 1 |
| Box Weight Brutto (kg) | 9 kg |
| Retail Packaging Net Weight Carton | 0.25 kg |
| Retail Packaging Net Weight Plastic | 0 kg |
| Packs in Box | 5 |
| Package Type | Box |
| EAN Code | 4711387491904 |
