Description
APC SMX3000RMHV2UNC 3000VA USB/RS/AP9631/LCD/RT 2U
Specifications
| Description | APC Smart-UPS X 3000VA Rack/Tower LCD 200-240V with Network Card APC Smart-UPS,2700 Watts /3000 VA ,Input 208V, 230V/Output 230V, Interface Port SmartSlot, Extended runtime model, Rack Height 2 U |
|---|---|
| Apparent power | 3000 VA |
| Active power | 2700 |
| UPS Architecture | line-interactive |
| Number of phases input | 1 (230V) |
| No. of batteries | 1 |
| Voltage | 120 |
| Battery capacity | 600 |
| Hold-up time (maks) | 4 |
| Backup time (100% load) | 6.3 |
| Charging time | 3 |
| Chassis type | Rack |
| Chassis type | Tower |
| Special functions | - Boost and Trim Automatic Voltage Regulation (AVR) - Intelligent battery management - Power conditioning - Temperature-compensated battery charging - Automatic restart of loads after UPS shutdown - Automatic self-test - Disconnected battery notification - Network manageable - Audible alarms - LED status indicators - Serial connectivity - USB connectivity - Disconnected battery notification - User-replaceable batteries - Hot-swappable batteries - Predictive failure notification - Resettable circuit breakers - Battery failure notification - Adjustable voltage-transfer points - Adjustable voltage sensitivity - Safety-agency approved |
| Input power ports | IEC-C20 |
| Input power ports | Type F Schuko |
| Input power ports | Type G British |
| Output power ports | 8 x IEC-C13 |
| Output power ports | 1 x IEC-C19 |
| Connectors | SmartSlot |
| Environment requirements | - Operating Environment : 0 - 45 ° C - Relative Humidity : 0 - 95 % - The height above sea level Operating: 0-3000 m - Temperature ( storage) : -15 - 45 ° C - Relative humidity (storage) 0 - 95 % - The height above sea level (storage) : 0-15000 m - The noise level at 1 meter from surface of unit 55.00 dBA - Dissipation : 184.00 BTU / hr . |
| Accessories included | - CD with software - Rack Mounting support rails - Smart UPS signalling RS-232 cable - Temperature Probe - User Manual - Web/SNMP Management Card |
| Color | Black |
| Dimensions | - Height: 85 mm - Width: 432 mm - Depth: 667 mm - Rack Height 2U |
| Weight | 37.32 |
| Other features | - Output Power: 2700W - Output voltage: 208/220 /230/ 240V - Waveform Type : Sine wave - Crest Factor : 3: 1 - 2 x IEC Jumpers - Input voltage: 208 /230V , 140-280V - Cord Length : 1.83 m - Emergency power supply - Surge energy rating : 645 joules |
