Beschreibung
Zyxel Switch XGS1935-52HP-EU0101F
Specifications
| Description | 48-Port GbE PoE Lite-L3 Smart Managed Switch with 4× 10G Uplink Ports The Zyxel XGS1935 series is a family of Lite-L3 smart managed switches, consisting of four models, including 28- and 52-port variants, with and without PoE. All four models feature four additional 10GbE fiber ports to meet your companys growing demand for high-speed networking. The series is equipped with an intelligent fan that automatically adjusts its speed based on device temperature, ensuring near-silent switch operation. |
|---|---|
| Switch class | Managed |
| Application | Medium and large companies |
| Switch layer | L3 |
| Network architecture | GigabitEthernet |
| Number of 10/100 Mbps ports | None |
| Number of 10/100/1000 Mbps ports | 48 |
| 10/100/1000/2500 Mbps ports | None |
| Number of 10Gb ports | None |
| Number of ports 25Gb | None |
| Number of PoE ports (PoE & PoE+) | None |
| Number of PoE+ ports | None |
| Number of COMBO ports | None |
| Number of SFP ports | None |
| Number of SFP+ ports | 4 |
| Number of SFP56 ports | None |
| Number of QSFP+ ports | None |
| Throughput | 176 |
| Forwarding rate | 130.9 |
| Memory buffer | 1.5 |
| MAC address table size | 16000 |
| Support for Jumbo frames | Yes |
| Jumbo frame size | 9 |
| Supported protocols and standards | IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab 1000BASE-T Ethernet IEEE 802.3z 1000BASE-X IEEE 802.3ae 10-Gigabit Ethernet Over Fiber IEEE 802.3af PoE IEEE 802.3at PoE Plus IEEE 802.3az EEE IEEE 802.3x flow control IEEE 802.3ad LACP aggregation IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) IEEE 802.1p Class of Service (CoS) prioritization IEEE 802.1X port authentication |
| Chassis type | Rack |
| Fan | Yes |
| Power supply | Internal |
| Power consumption | 470.1 |
| Mean time between failures (MTBF) | 562941 |
| Environment requirements | Operating: Temperature: -20°C to 50°C Humidity: 10% to 95% (non-condensing) Storage: Temperature: -40°C to 70°C Humidity: 10% to 95% (non-condensing) |
| Certificates | LVD, BSMI, EMC, FCC Part 15 (Class A), CE (Class A), BSMI EMC, RoHS Level A |
| Accessories included | Power cable Rack-mount kit |
| Dimensions | 440 x 270 x 43 mm |
| Weight | 4.1 |
