Specifications
| Data Link Protocol Supports | Gigabit Ethernet Fast Ethernet Ethernet |
|---|---|
| Number of Ports | 9 |
| Switching Protocol | Ethernet |
| Switching Layers | Layer 3 |
| MAC Address Table Size | 8K |
| Network/Transport Protocol | IPv4 DHCP IGMP STP RSTP LLDP |
| LAN Management Protocol Supported | AR |
| Networking Compliant Standards | IEEE 802.1Q(VLAN) IEEE 802.1X |
| Networking Features | Jumbo Frames Support MAC address filtering Access Control List 4 Ports PoE+ Egress Rate Limit Flow Control Storm Control Multicast & Broadcast Rate Limiting Port Isolation Port Mirroring Loop Protection LACP Port Aggregation 4 Ports PoE++ LCD Touchscreen Built-in Integrated Backup Battery (Li-ion 368Wh) |
| Device Location | External |
| Mounting Capability | Rackmount |
| Standard Rack Height | 1U |
| Certifications | CE, FCC, IC, Anatel: 06679-25-08356 |
| Included Accessories | Rack Mounting Kit Power Cable |
| LAN | 9 (RJ-45) |
| DC Battery Port | 1 |
| Power Supply | Internal AC 100-240 V, 50 60 Hz |
| Power Consumption Operational | 50 W |
| Depth (mm) | 480 mm |
| Height (mm) | 44 mm |
| Width (mm) | 442 mm |
| Nominal Weight | 9 kg |
| External Color | Gray |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 95 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 5 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 12 month(s) |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 635 mm |
| Pack Width (mm) | 215 mm |
| Pack Height (mm) | 770 mm |
| Pack Weight Brutto (kg) | 14.613 kg |
| Pack Weight Netto (kg) | 0 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 639 mm |
| Box Width (mm) | 213 mm |
| Box Height (mm) | 777 mm |
| Box Weight Brutto (kg) | 16.36 kg |
| Retail Packaging Net Weight Carton | 0 kg |
| Retail Packaging Net Weight Plastic | 0 kg |
| Packs in Box | 1 |
| Package Type | Retail |
| EAN Code | 810010079879 |
| Economic operator in EU / authorized rep | Ubiquiti International Holding B.V. |
| Postal address | Ekkersrijt 3102. Son en Breugel, 5692 CC., The Netherlands |
| Electronic address | legal@ui.com |
