Specifications
| Data Link Protocol Supports | 10 Gbps Fast Ethernet Ethernet 1 Gbps 5 Gbps 25 Gbps |
|---|---|
| Number of Ports | 24 |
| Total Number of Ports | 26 |
| Switching Protocol | Ethernet |
| Switching Layers | Layer 2 Layer 3 |
| MAC Address Table Size | 128K |
| Network/Transport Protocol | IPv4 ARP DHCP QoS IGMP STP RSTP LLDP NDI |
| LAN Management Protocol Supported | Ethernet, AR |
| Networking Compliant Standards | IEEE 802.1Q(VLAN) IEEE 802.1X IEEE 802.3bt |
| Networking Features | DHCP Server Built-in Jumbo Frames Support Egress Rate Limit Flow Control Storm Control Multicast & Broadcast Rate Limiting Port Isolation Port Mirroring Loop Protection 24 Ports 4PPoE Etherlighting DHCP Relay LACP Port Aggregation Touchscreen |
| Device Location | External |
| Mounting Capability | Rackmount |
| Standard Rack Height | 1U |
| Certifications | CE, FCC, IC, Anatel |
| Included Accessories | Power Cable Mount kit |
| LAN | 24 (RJ-45) 2 (SFP28) |
| Power Supply | Internal AC 100-240 V, 50 60 Hz |
| Power Consumption Operational | 150 W |
| Depth (mm) | 480 mm |
| Height (mm) | 44 mm |
| Width (mm) | 442 mm |
| Nominal Weight | 7.9 kg |
| External Color | Gray |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | -5 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 24 month(s) |
| Warranty Validation Criteria | Serial Number |
| Warranty Term Notes | 24 months - for EU |
| Pack Length (mm) | 680.5 mm |
| Pack Width (mm) | 509 mm |
| Pack Height (mm) | 144 mm |
| Pack Weight Brutto (kg) | 13.8457 kg |
| Pack Weight Netto (kg) | 9.346 kg |
| Pieces in pack | 1 |
| Box Length (mm) | 769 mm |
| Box Width (mm) | 593 mm |
| Box Height (mm) | 237 mm |
| Box Weight Brutto (kg) | 13.8457 kg |
| Retail Packaging Net Weight Carton | 0 kg |
| Retail Packaging Net Weight Plastic | 0 kg |
| Packs in Box | 1 |
| Package Type | Retail |
| EAN Code | 810177160762 |
