TrinaSolar TrinaSolar 470 W VERTEX S+ NED9R.28 N-Type Monofacial Dual Glass i-TOPCon Monocrystalline TSM-NED9R.28 470W

TrinaSolar TrinaSolar 470 W VERTEX S+ NED9R.28 N-Type Monofacial Dual Glass i-TOPCon Monocrystalline TSM-NED9R.28 470W

Producer: TrinaSolar

Key Features

Package features

• Gross depth (mm): 30
• Gross height (mm): 1765
• Gross width (mm): 1135
• Packing quantity: 1.00
• Paper/Pasteboard: 800.00
• Plastic (No PET): 200.00
• Tare weight (kg): 1.00
• Volume (m3): 0.06009825
• Embeeded battery: No
• WEEE tax: Yes
• WEE classification: CL109:4B:2024-01-01
• Palette Qty: 36

Technical details

• Gross weight: 28.00
• Net weight: 27.00
• Producer: TrinaSolar
• Peak power: 470
• Number of cells: 144
• Module weight: 27
• Module Dimensions: 1762 x 1134 x 30
• J-Box: IP68
• Solar Cells: Monocrystalline
• Producer product name: VERTEX S+ NED9R.28
• Producer product family: N-Type Monofacial Dual Glass i-TOPCon Monocrystalline

Power

• Maximum Power Voltage: 46.1
• Open Circuit Voltage: 54.6
• Short Circuit Current: 10.89
• Efficiency: 23.8

Operational conditions

• Maximum System Voltage: 1500
• Operating temperature (T-T): -40 to +70
• Temperature Coefficient of PMAX: -0.29%/°C
• Temperature Coefficient of VOC: -0.24%/°C
• Temperature Coefficient of ISC: 0.04%/°C

Warranty

• First year degradation: 1
• Annual power degradation: 0.4

Other

• Warranty: 300
